日本新光電子秤LN31001 31kg/0.1g

LN系列分析天平



Model	LN 223	LN 323	LN 423	LN 623	LN 1202	LN 2202	LN 3202
Capacity	220g	320g	420g	620g	1200g	2200g	3200g
Readability	0.001g				0.01g
Repeatability(s)	0.001g				0.01g
Non-Linearity(typ.)	0.001g				0.01g
Pan size	120×140mm				200×200mm
Calibration	with external weight only
Weighing Units	g ct oz lb dwt GN tl(Hong Kong) tl(Taiwan) tl(Singapore) momme tola
Dimensions(LWH)	330×220×190mm(including windshield)				333x220x88mm
Weights	Approx. 3.5kg				Approx. 4.0kg



Model	LN 4202	LN 6202	LN 8201	LN 12001	LN 15001	LN 21001	LN 31001
Capacity	4200g	6200g	8200g	12000g	15000g	21000g	31000g
Readability	0.01g		0.1g
Repeatability(s)	0.01g		0.1g
Non-Linearity(typ.)	0.01g		0.1g
Pan size	200×200mm		200×200mm			220×250mm
Calibration	with external weight only
Weighing Units	g ct oz lb dwt GN tl(Hong Kong) tl(Taiwan) tl(Singapore) momme tola
Dimensions(LWH)	330×220×88mm		333x220x88mm			333x220x111mm
Weights	Approx. 4.0kg					Approx. 8.5kg	Approx. 9.5kg

INTERNAL WEIGHT MODELS


Model	LN 223R	LN 323R	LN 423R	LN 623R	LN 1202R	LN 2202R	LN 3202R	LN 4202R
Capacity	220g	320g	420g	620g	1200g	2200g	3200g	4200g
Readability	0.001g				0.01g
Repeatability(s)	0.001g				0.01g
Non-Linearity(typ.)	±0.001g				±0.01g
Pan size	120×140mm				200×200mm
Calibration	with internal and external weight
Weighing Units	g ct oz lb dwt GN tl(Hong Kong) tl(Taiwan) tl(Singapore) momme tola
Dimensions(LWH)	330×220×190mm(including windshield)				333x220x88mm
Weights	Approx. 3.5kg				Approx. 4.0kg

When you need OIML approval model please refer the specifications of CE model
INTERNAL WEIGHT CE MODELS


Model	LN 223RCE	LN 323RCE	LN 423RCE	LN 623RCE	LN 1202RCE	LN 2202RCE	LN 3202RCE	LN 4202RCE
Capacity	220g	320g	420g	620g	1200g	2200g	3200g	4200g
Read-out(d)	0.001g				0.01g
Verification(e)	0.01g				0.1g
Repeatability(s)	0.001g				0.01g
Non-Linearity(typ.)	±0.001g				±0.01g
Pan size	120×140mm				200×200mm
Calibration	with internal and external weight
Dimensions(LWH)	330×220×190mm(including windshield)				333x220x88mm
Weights	Approx. 3.5kg				Approx. 4.0kg

EXTERNAL WEIGHT CE MODELS


Model	LN 223CE	LN 323CE	LN 423CE	LN 623CE	LN 1202CE	LN 2202CE	LN 3202CE
Capacity	220g	320g	420g	620g	1200g	2200g	3200g
Read-out(d)	0.001g				0.01g
Verification(e)	0.01g				0.1g
Repeatability(s)	0.001g				0.01g
Non-Linearity(typ.)	±0.001g				±0.01g
Pan size	120×140mm				200×200mm
Calibration	with external weight only
Dimensions(LWH)	330×220×190mm(including windshield)				333x220x88mm
Weights	Approx. 3.5kg				Approx. 4.0kg



Model	LN 4202CE	LN 6202CE	LN 8201CE	LN 12001CE	LN 15001CE	LN 21001CE	LN 31001CE
Capacity	4200g	6200g	8200g	12000g	15000g	21000g	31000g
Read-out(d)	0.01g		0.1g
Verification(e)	0.1g		1g
Repeatability(s)	0.01g		0.1g
Non-Linearity(typ.)	±0.01g		±0.1g
Pan size	200×200mm		200×200mm			220×250mm
Calibration	with external weight only
Dimensions(LWH)	330×220×88mm		333x220x88mm			333x220x111mm
Weights	Approx. 4.0kg					Approx. 8.5kg	Approx. 9.5kg

Common Specifications


Power source	AC120/230V DC12V
Output	RS232C (2 outputs)
Measuring system	音叉式傳感器
Tare	全量程測量范圍
Display	熒光顯示屏



LNBT	可充電電池
LNLM	繼電器觸點
LNUH	重下鉤
LNBZ	蜂鳴器輸出
LNR4	RS422A 輸出
LNDK	密度測量工具
